Features

Straight tonearm contributes to sound transparency and openness

Belt-drive turntable

Switchable Phono and Line output

Authentic Hi-Fi design

Specifications

Turntable Drive Method Belt drive

Motor DC motor

Rotation Speed 33-1/3 rpm, 45 rpm

Rotation Speed Variation ±2%

Wow And Flutter 0.2%

Platter Aluminium die-cast (Diameter 30 cm)

Output Level 140 mV (-17 dBV, with RIAA EQ), 2.5 mV ± 3 dBV (without RIAA EQ, 1 kHz, 3.54 cm / sec)

Signal To Noise Ratio 67 dB or higher (A-weighted, 20 kHz, LPF)

Tonearm Static balance straight tonearm

Effective Arm Length 223.5 mm

Overhang 19 mm

Stylus Pressure Adjustment Range 0-4 g

Acceptable Cartridge Weght 15.5-19 g (including headshell)

Attached Cartridge     Cartridge Type     MM type

Output Voltage 2.5 mV (1 kHz, 3.54 cm / sec)

Stylus Pressure 3.5 ± 0.5 g

Cartridge Weight 5.0 ± 0.3 g

Cartridge Height 17.0 ± 0.7 mm

Head-shell Weight 10 g (including screws, nuts and wires)

Audio Specifications Output Terminal     RCA: 1 (PHONO)

General Power Consumption 1.5 W

Standby Power Consumption 0.1 W

Dimension (W×H×D) 450 x 136 x 368 mm

Weight 4.8 kg
